Technical parameter

WYQ-24

6

16

30

45

75

100

140

180

260

320

400

500

Max.bending    section modulus

6

16

30

45

75

100

140

180

260

320

400

500

Rolling speed(m/min)

6

5

4

Yield strength(mpa)

S=450

Angle,inside bending

Max.bending size(mm)

40x5

70x8

80x8

90x10

100x10

120x12

140x16

150x16

160x16

180x14

200x18

200x20

Angle,outside bending

Max.bending size(mm)

50x5

80x8

90x10

100x10

120x12

140x16

150x16

160x16

180x14

200x18

200x24

250x25

U-steel outside bending

Max.bending size(mm)

8

12

16

20

25

28

30

32

36

40

45

50

U-steel inside bending

Max.bending size(mm)

8

12

16

20

25

28

30

32

36

40

45

50

Flat horizontal bending

Max.bending size(mm)

100x8

150x25

180x25

200x30

220x40

250x40

280x50

300x50

330x50

360x60

400x75

500x76

Flat vertical bending

Max.bending size(mm)

50x12

75x16

90x20

100x25

110x4

12x40

150x40

180x30

190x40

190x50

200x50

200x60

Round pipe

Max.bending size(mm)

42x4

76x4.5

89x5

89x8

114x5

159x5

186x6

168x8

219x8

245x8

273x8

323x10

Round steel

Max.bending size(mm)

38

52

62

75

85

90

100

110

120

135

150

160

Square steel

Max.bending size(mm)

45x3

60x4

70x4

80x6

90x8

100x10

125x10

140x10

150x10

165x10

180x12

200x12
