Mechanical 3-Roller Symmetrical Plate Rolling Machine
Scan the QR code
Model | Max.Bending thickness(mm) | Max.Bending width(mm) | Yield limit(mm) | Coiling Speed(m/min) | Top roller diameter(mm) | Bottom roller diameter(mm) | Central distance(mm) | Main power (kw) |
W11-4x1500 | 4 | 1500 | 245 | 5 | 150 | 140 | 200 | 4 |
W11-4x2000 | 4 | 200 | 245 | 5 | 160 | 150 | 220 | 4 |
W11-6x1500 | 6 | 1500 | 245 | 5 | 160 | 150 | 220 | 4 |
W11-6x2000 | 6 | 2000 | 245 | 5 | 170 | 160 | 220 | 5.5 |
W11-6x2500 | 6 | 2500 | 245 | 4.5 | 180 | 170 | 250 | 5.5 |
W11-8x1500 | 8 | 1500 | 245 | 5 | 170 | 160 | 220 | 5.5 |
W11-8x2000 | 8 | 2000 | 245 | 4.5 | 180 | 170 | 250 | 5.5 |
W11-8x2500 | 8 | 2500 | 245 | 4.5 | 240 | 180 | 280 | 7.5 |
W11-12x2000 | 12 | 2000 | 245 | 4.5 | 240 | 180 | 280 | 7.5 |
W11-12x2500 | 12 | 2500 | 245 | 4.5 | 260 | 220 | 320 | 11 |
W11-12x3000 | 12 | 3000 | 245 | 4 | 280 | 240 | 360 | 11 |
W11-16x2000 | 16 | 2000 | 245 | 4.5 | 260 | 220 | 320 | 11 |
W11-16x2500 | 16 | 2500 | 245 | 4 | 280 | 240 | 360 | 11 |
W11-16x3000 | 16 | 3000 | 245 | 4 | 340 | 270 | 440 | 15 |
W11-20x2000 | 20 | 2000 | 245 | 4 | 280 | 240 | 360 | 11 |
W11-20x2500 | 20 | 2500 | 245 | 4 | 340 | 270 | 440 | 15 |
W11-25x2000 | 25 | 2000 | 245 | 4 | 340 | 270 | 440 | 15 |
W11-25x2500 | 25 | 2500 | 245 | 4 | 370 | 280 | 480 | 22 |
W11-30x2000 | 30 | 2000 | 245 | 4 | 370 | 270 | 480 | 22 |
W11-30x2500 | 30 | 2500 | 245 | 4 | 420 | 360 | 550 | 30 |
W11-30x3000 | 30 | 3000 | 245 | 4 | 450 | 390 | 600 | 30 |
W11-40x2500 | 40 | 2500 | 245 | 4 | 500 | 400 | 600 | 37 |
