Hydraulic CNC Pipe Bending Machine
Specification | |||
Mold | DW-18CNC-3A Servo Bend | DW-18CNC-4A-2S Servo Bend | |
Max.Tube o.d. Bending Capacity | ⲫ18x1.8mm | ⲫ18x1.8mm | |
Tooling stack | 1 | 2 | |
CLR | 15-100mm | 15-100mm | |
Max.Bending Radius Difference S1-S2 | \ | 40mm | |
Max.Bending Angle | 190° | 190° | |
Max.Mandrel working Distance | 1000mm | 1000mm | |
Processing Speed | Tube Feeding Speed | 900mm/sec | 900mm/sec |
Tube Rotation Speed | 540°/sec | 540°/sec | |
Tube Bending Speed | 90°/sec | 90°/sec | |
Repeatability | Tube Feeding Precision | ±0.1mm | ±0.1mm |
Tube Rotation Precision | ±0.1° | ||
Tube Bending Precision | ±0.1° | ±0.1° | |
Total Motor Power | 7.0kw | 7.5kw | |
Overall Weight | 700kg | 750kg | |
Machine Length | 2800x800x1400mm | 2800x850x1400mm |
