Model

WLL-SRS350

Amount of Rollers

1+

Max.Diameter of Material

Φ350 mm

Max.Length of Work Piece

400 mm

Thickness of Work Piece

0.5-2.0 mm(Aluminum,Copper)

0.5-1.2 mm(Carbon Steel)

0.5-1.0 mm(Stainless Steel)

X Trave

300 mm

Z Trave

380 mm

Spindle Speed

4000 rpm

Travel of Tailstock

300 mm

Amount of Tools

2+2/ Optional

Main Motor Power

3.7 kw Servo

Positioning Accuracy

0.01
