No.

Model

WLH-DRS1550

1

Amount of Rollers

2

2

Max. Diameter of Material

Ø1550 mm

3

Thickness of Work Piece

1-20.0mm (Aluminum, Copper)

1-12.0mm (Carbon Steel)

1-6.0mm (Stainless Steel)

4

X Travel

550 mm

5

Z Travel

1100 mm(30°)

6

Travel of Tailstock

1200 mm

7

Pushing Force of Tailstock

60KN

8

Amount of Tools

6+6

9

Spindle Motor Power

100KW servo

10

Weight (KG)

48000
