CWA series Heavy Duty Lathe Machine
Scan the QR code
MODEL | CWA61100 | CWA61125 | CWA61140 | CWA61160 |
CWA62100 | CWA62125 | CWA62140 | CWA62160 | |
Max.weight of workpiece | 8T | |||
Max.swing over bed | 1000mm | 1250mm | 1400mm | 1600mm |
Max.swing over cross slide | 620mm | 870mm | 1000mm | 1200mm |
Max swing over gap | 1300mm | 1550mm | 1700mm | 1900mm |
Valid length of gap | 450mm | |||
Center distance | 1.5m 2m 3m 4m 5m 6m 8m 10m 12m | |||
Width of bed | 780mm | |||
Spindle hole | Φ130mm | |||
Spindle taper | Metric 140# | |||
Spindle speeds | 3.15-315r/min or 2.5-250r/mm. series:+21kinds,-12kinds | |||
Metric threads range(kinds) | 44 kinds 1-120mm | |||
Inch threads range(kinds) | 31 kinds 1/4-24牙/时 | |||
Moudle threads range(kinds) | 45 kinds 0.5-60mm | |||
Diametral threads range(kinds) | 38 kinds 1/2-56DP | |||
Longitudinal feeds range(kinds) | 56 kinds 0.1-12mm | |||
Cross feed range(kinds) | 56 kinds 0.05-6mm | |||
Rapid feed:Long/Cross | 3400mm/min,1700mm/min | |||
Distance between Center & Tool | 48mm | |||
Tool section | 45*45mm | |||
Cross slide travel | 650mm | |||
Compound rest travel | 280mm | |||
Sleeve diameter | Φ160mm | |||
Sleeve taper | Metric 80# | |||
Sleeve travel | 300mm | |||
Main motor | 22kw | |||
Coolant motor | 0.15kw | |||
Rapid feed motor | 1.5kw |
