Bandsaw Machine
$9,000-12,000 Get a quote

Gantry Horizontal Metal Band Sawing Machine

Model: G4265

Scan the QR code

Model

G4265/80

Max. Cutting Diameter

Round: 650mm

Plate: 650*800mm

Blade Speed

20*40*60m/min

Blade Size

1.6*54*6700mm

Motor Output

5.5kw

Hydraulic Pressure

2.2kw

Coolant Pump

0.125kw

Table height

550mm

Machine Size(L*W*H)

4350*3000*2850mm

Net Weight

5500kg

Vice clamping

Hydraulic(Double pairs )

Blade tensioning form

Hydraulic

Feeding cut adjust way

Hydraulic stepless

Feeding way

Automatic(hydraulic cylinder)

Hydraulic cooling way

Wind cooling

Chip conveyor way

Manual

Voltage

380V 50HZ 3Phase



Description

Gantry Horizontal Metal Band Sawing Machine


Gantry Horizontal Metal Band Sawing Machine
