Model

HL-320SK

Max. Cutting Diameter

Round: 320mm

Plate: 320*320mm

Blade Speed

20-70m/min by Inverter

Blade Size

1.1*34*4115mm

Motor Output

3kw

Hydraulic Pressure

0.75kw

Coolant Pump

0.09kw

Table height

630mm

Machine Size(L*W*H)

2300*2100*1500mm

Net Weight

1600kg

Vice clamping

Hydraulic(two pairs)

Blade tensioning form

Manual

Feeding cut adjust way

Hydraulic

Precision of feeding

0.2mm-/+

Feeding way

Automatic(hydraulic oil cylinder)

Hydraulic cooling way

Wind cooling

Chip conveyor way

Manual

Voltage

380V 50HZ 3Phase
